PESD5V0V1BL,315 Nexperia USA Inc. PESD5V0V1BL,315 real image PESD5V0V1BL,315 label picture PESD5V0V1BL,315 label picture 2
Same model may have multiple batches, images only for reference.
PESD5V0V1BL,315 Nexperia USA Inc. PESD5V0V1BL,315 real image PESD5V0V1BL,315 label picture PESD5V0V1BL,315 label picture 2
PESD5V0V1BL,315 Nexperia USA Inc. PESD5V0V1BL,315 real image PESD5V0V1BL,315 label picture PESD5V0V1BL,315 label picture 2
Same model may have multiple batches, images only for reference.

PESD5V0V1BL,315

Part No PESD5V0V1BL,315
Manufacturer Nexperia USA Inc.
Catalog TVS - Diodes
Description TVS DIODE 5VWM 12.5VC SOD882
Datasheet
PESD5V0V1BL,315 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 1
STAND-OFF Voltage (Vwm) 5V (Max)
Minimum Breakdown Voltage 5.8V
Max Clamping Voltage 12.5V
Peak Pulse Current(Ippm) 4.8A (8/20μs)
Power Dissipation - Pd 45W
Applications Automotive
Capacitance @ Frequency 11pF @ 1MHz
Temperature Range - Operating -55°C to 150°C (TA)
Mounting SMD (SMT)
Case / Package SOD-882
Win Source Part Number 1087619-PESD5V0V1BL,315
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PESD5V0V1BL,315 CAD Model

Description

The PESD5V0V1BL,315 is a bidirectional zener diode from Nexperia USA Inc.

  • Capacitance: 11pF @ 1MHz
  • Suitable for: Automotive applications
  • Stand-off Voltage: 5V (Max)
  • Minimum Breakdown Voltage: 5.8V
  • Maximum Clamping Voltage: 12.5V
  • Peak Pulse Current: 4.8A (8/20μs)
  • Package: SOD-882
  • Power Dissipation: 45W
