2N7002P,215 2N7002P,215 real image24503 2N7002P,215 real image24504 2N7002P,215 Real Image1 2N7002P,215 Real Image2
Same model may have multiple batches, images only for reference.
2N7002P,215 2N7002P,215 real image24503 2N7002P,215 real image24504 2N7002P,215 Real Image1 2N7002P,215 Real Image2
2N7002P,215 2N7002P,215 real image24503 2N7002P,215 real image24504 2N7002P,215 Real Image1 2N7002P,215 Real Image2
Same model may have multiple batches, images only for reference.

2N7002P,215

Part No 2N7002P,215
Manufacturer Nexperia USA Inc.
Catalog TRANSISTORS
Description MOSFETs 60 V, 360 mA N-channel Trench MOSFET
Datasheet
2N7002P,215 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Nexperia
Technology Si
Mounting Style SMD/SMT
Package / Case SOT-23-3
Transistor Polarity N-Channel
Number of Channels 1 Channel
Vds - Drain-Source Breakdown Voltage 60 V
Id - Continuous Drain Current 360 mA
Rds On - Drain-Source Resistance 1.6 Ohms
Vgs - Gate-Source Voltage - 20 V, + 20 V
Vgs th - Gate-Source Threshold Voltage 1.1 V
Qg - Gate Charge 600 pC
Minimum Operating Temperature - 55 C
Maximum Operating Temperature + 150 C
Pd - Power Dissipation 420 mW
Channel Mode Enhancement
Packaging Cut Tape
Packaging MouseReel
Packaging Reel
Brand Nexperia
Product Type MOSFETs
Standard Pack Qty 3000
Subcategory Transistors
Ultra Librarian 3D Model Ultra Librarian 2N7002P,215 CAD Model

Description

The Nexperia 2N7002P,215 is an N-channel MOSFET transistor designed for use in electronic circuits that require switching.

  • Voltage Rating: 60V
  • Family: 2N7002
  • Supply and Demand: Limited
  • Units per Package: 3000
