LMS4684ITL

Part No LMS4684ITL
Manufacturer National Semiconductor (TI)
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description SPDT, 2 FUNC PBGA12
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Interface - Analog Switches, Multiplexers, Demultiplexers
Mfr National Semiconductor (TI)
Series LMS4684
Package Bulk
Product Status Active
Switch Circuit SPDT - NC/NC
Number of Circuits 2
On-State Resistance (Max) 800mOhm
Channel-to-Channel Matching (ΔRon) 1.11mOhm
Voltage - Supply, Single (V+) 1.8V ~ 5.5V
Switch Time (Ton, Toff) (Max) 60ns, 40ns
Charge Injection 200pC
Current - Leakage (IS(off)) (Max) 10nA
Crosstalk -72dB @ 100kHz
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case 12-WFBGA, DSBGA
Supplier Device Package 12-DSBGA (2x2.5)
Standard Package 250 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 619260-LMS4684ITL
Ultra Librarian 3D Model Ultra Librarian LMS4684ITL CAD Model

Description

The 619260-LMS4684ITL is an analog switch integrated circuit designed for interface applications.

  • Series: LMS4684
  • Package: Bulk
  • Circuits: 2
  • Switch Circuit: SPDT - NC/NC
  • Maximum On-State Resistance: 800mOhm
  • Charge Injection: 200pC
  • Supply Voltage Range: 1.8V to 5.5V
  • Features: Fast switching time and low crosstalk
  • Mounting: Surface Mountable
  • Package: 12-DSBGA
  • Operating Temperature: -40°C to 85°C
