Same model may have multiple batches, images only for reference.
78602/3MC Real Image
Same model may have multiple batches, images only for reference.

78602/3MC

Part No 78602/3MC
Manufacturer Murata Power Solutions Inc.
Catalog Pulse Transformers
Description PULSE XFMR 1:1:1 200UH  /  200µH General Purpose Pulse Transformer 1:1:1 Surface Mount
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Transformers>Pulse Transformers
Mfr Murata Power Solutions Inc.
Series 786
Package Tube
Product Status Not For New Designs
Transformer Type General Purpose
Inductance 200µH
ET (Volt-Time) 6VµS
Mounting SMD (SMT)
Dimension 0.375" L x 0.354" W (9.52mm x 9.00mm)
Height - Seated (Max) 0.250" (6.35mm)
Temperature Range - Operating 0°C ~ 70°C
Base Product Number 78602
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.31.2000
Standard Package 50
Win Source Part Number 1181221-78602/3MC
Ultra Librarian 3D Model Ultra Librarian 78602/3MC CAD Model

Description

It is a pulse transformer with a part number of 1181221-78602/3MC and a series of 786.

  • Component Type: Pulse Transformer
  • Series: 786
  • Transformer Type: General Purpose
  • Inductance: 200μH
  • Package: Tube
  • Mounting: SMD (SMT)
  • Operating Temperature: 0°C to 70°C
