TRC105 RF Monolithics, Inc
Same model may have multiple batches, images only for reference.

TRC105

Part No TRC105
Manufacturer Murata Electronics North America
Catalog RF Transceiver ICs
Description IC RF TXRX ISM<1GHZ 32WFQFN
Datasheet
TRC105 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - RF Transceiver ICs
Mfr Murata Electronics North America
Package Tape & Reel
Product Status Obsolete
Programmable Not Verified
Type TxRx Only
RF Family/Standard General ISM < 1GHz
Modulation FSK, OOK
Frequency 300MHz ~ 510MHz
Data Rate (Max) 200kbps
Power - Output 13dBm
Sensitivity -112dBm
Serial Interfaces SPI
Voltage - Supply 2.1V ~ 3.6V
Current - Receiving 2.7mA
Current - Transmitting 16mA ~ 25mA
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case 32-WFQFN Exposed Pad
Supplier Device Package 32-QFN (5x5)
Base Product Number TRC10
Standard Package 3,000 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.31.0001
Win Source Part Number 691193-TRC105
Ultra Librarian 3D Model Ultra Librarian TRC105 CAD Model

Description

The TRC105 is an RF transceiver IC from Murata Electronics.

  • Frequency Range: 300MHz to 510MHz
  • Type: TxRx only
  • Modulation: FSK and OOK
  • Maximum Output Power: 13dBm
  • Sensitivity: -112dBm
  • Data Rate: Up to 200kbps
  • Supply Voltage: 2.1V to 3.6V
  • Receiving Current: 2.7mA
  • Transmitting Current: 16mA to 25mA
  • Mounting Type: Surface Mountable
  • Package: 32-WFQFN exposed pad
