The Molex 90147-1106 is a Micro-Fit 3.0 connector header. These headers are designed for wire-to-board connections, offering a compact and reliable solution for power and signal applications. With a 3.0mm pitch, Micro-Fit connectors balance current-carrying capacity with space savings, making them suitable for a wide variety of electronic devices.

Applications

• Power supplies
• Industrial controls
• Robotics
• Consumer electronics
• Automotive electronics

Features

• Compact Design: 3.0mm pitch maximizes space efficiency.
• Positive Locking: Ensures secure mating and prevents accidental disconnections.
• Durable Construction: Made from high-quality materials for long-lasting performance.
• Polarization: Prevents incorrect mating, ensuring proper circuit connections.
• Through-Hole Mounting: Designed for secure attachment to printed circuit boards.

Benefits

• Reliable Connection: Provides a stable and consistent electrical connection.
• Space Savings: Enables high-density packaging in electronic devices.
• Ease of Assembly: Simplifies the manufacturing process.
• Reduced Downtime: Minimizes the risk of connection failures.
• Versatile Application: Suitable for a wide range of industries and applications.

Additional Details

The 90147-1106 is a through-hole header, meaning it is designed to be soldered directly onto a printed circuit board. It is made from high-temperature thermoplastic, allowing it to withstand reflow soldering processes. The header is designed to mate with corresponding Micro-Fit 3.0 receptacles. Refer to the Molex datasheet for specific details on current rating, voltage rating, and mating compatibility.
