90136-1208 Real Image
Same model may have multiple batches, images only for reference.

90136-1208

Part No 90136-1208
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Shrouded Header (4 Sides) HDR 8 POS 2.54mm Solder ST Top Entry Thru-Hole Package
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Contact Gender Male
Contact Material Brass, Copper
Contact Plating Gold
Contact Resistance 20 mΩ
Country of Origin SK
Current Rating 3 A
Gender Male
Glow Wire Compliant Non-compliant
Housing Color Black
Housing Material Polyester
Insulation Resistance 5 GΩ
Lead Free Yes
Lead Pitch 2.54 mm
Material Glass, Polyester
Maximum Operating Temperature 125 °C
Max Voltage Rating (AC) 350 V
Min Operating Temperature -55 °C
Mount Through Hole
Number of Circuits 8
Number of Contacts 8
Number of Pins 8
Number of Poles 8
Number of Positions 8
Number of Rows 1
Orientation Vertical
Pitch 2.54 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Schedule B 8536694040, 8536694040
Termination Through Hole
Voltage Rating 350 V
Voltage Rating (AC) 350 V
Voltage Rating (DC) 350 V
Working Voltage 350 V
Win Source Part Number 1024326-90136-1208
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 90136-1208 CAD Model

Description

The Molex 1024326-90136-1208 is a black, 1 row, 8 position through hole male connector.

  • Color: Black
  • Rows: 1
  • Positions: 8
  • Mounting Type: Through Hole
  • Connector Type: Male
  • Pitch: 2.54mm
  • Housing Material: Polyester
  • Contact Material: Brass and Copper
  • Contact Plating: Gold Plating
  • Contact Resistance: 20mΩ
  • Voltage Rating: 350V
  • Current Rating: 3A
  • RoHS Compliant: Yes
  • Lead-Free: Yes
  • Orientation: Vertical
  • Suitable for: Circular connectors - housings
