The Molex 87832-0406 is a Micro-Latch connector housing designed for secure and reliable wire-to-board connections. This component is part of Molex's extensive Micro-Latch series, known for its compact size and robust locking mechanism, making it suitable for applications where space is limited and connection integrity is critical.

Applications

• Consumer Electronics: Used in devices such as smartphones, tablets, and digital cameras for internal connections.
• Automotive: Employed in automotive electronics systems for connecting sensors, actuators, and control units.
• Industrial Automation: Utilized in industrial equipment and machinery for reliable signal and power connections.
• Medical Devices: Found in medical equipment where compact and secure connections are essential.
• Data and Telecommunications: Used in networking equipment and telecommunication devices for signal transmission.

Features

• Number of Circuits: 4
• Pitch: 1.25mm
• Housing Material: Durable plastic construction, typically with a UL 94V-0 flammability rating.
• Color: Natural (usually white or off-white)
• Polarization: Prevents mismating by ensuring correct orientation during connection.
• Latch Style: Micro-Latch provides a secure and audible click upon mating.

Benefits

• Space Optimization: The compact 1.25mm pitch allows for high-density connections in space-constrained environments.
• Reliable Connection: The Micro-Latch mechanism ensures a secure and dependable connection, minimizing the risk of accidental disconnections.
• Ease of Assembly: Designed for straightforward assembly with compatible Molex crimp terminals.
• Versatile Application: Suitable for a wide range of applications demanding compact and reliable connections.
• Durability: Constructed from high-quality materials for long-lasting performance and resistance to environmental factors.

Additional Details

The 87832-0406 connector housing is specifically designed to work with Molex Micro-Latch crimp terminals. These terminals are crimped onto the wires and then inserted into the housing, providing a secure electrical and mechanical connection. The housing offers insulation and protection for the terminals and ensures proper alignment when mated with a corresponding header or receptacle on a PCB.

The Micro-Latch feature provides a tactile and audible click when the connector is fully engaged, confirming a secure and reliable connection. This is especially important in applications where vibration or movement could potentially loosen less secure connections. The connector is designed for automated assembly processes, contributing to efficient manufacturing.
