The Molex 47053-3000 is a SlimStack™ Board-to-Board Connector. This connector is designed for parallel board stacking in applications where space is a premium. It provides a reliable electrical connection between two printed circuit boards, allowing for high-density packaging and efficient signal transfer.

Applications:

• Smartphones
• Tablets
• Laptops
• Wearable devices
• Digital cameras
• Portable media players
• Navigation systems
• Industrial control systems
• Medical equipment
• Automotive electronics

Features:

• SlimStack design for minimal stacking height
• 30 circuits/positions
• Fine pitch for high-density connections
• Surface mount termination
• High-temperature thermoplastic housing
• Secure locking mechanism
• RoHS compliant

Benefits:

• Maximum space savings due to ultra-low profile
• Increased board density due to fine pitch
• Reliable connection in demanding environments due to robust design
• Suitable for reflow soldering processes
• Durable performance over a wide temperature range
• Secure mating prevents accidental disconnection
• Environmentally friendly

Additional Details:

The 47053-3000 is a surface mount connector. The pitch is a fine pitch, typically 0.4mm. The stacking height is very low, enabling extremely thin device profiles. The housing material is a high-temperature thermoplastic, allowing it to withstand reflow soldering temperatures. The connector is typically gold-plated for improved conductivity and corrosion resistance. It is often used in applications where board space is severely limited, and a reliable, high-density connection is required. This connector is designed for automated pick-and-place assembly. The typical operating temperature range is -40°C to +85°C.
