The 38723-6512 is a Micro-Fit 3.0 receptacle housing manufactured by Molex, LLC. It is designed to provide a secure and reliable connection for wire-to-board and wire-to-wire applications, commonly used in various electronic systems.

Applications:

• Power Supplies: Connecting power cables to circuit boards.
• Data Communications: Connecting data cables in networking equipment and computer systems.
• Industrial Automation: Connecting control cables in machinery and automation systems.
• Consumer Electronics: Connecting various components in electronic devices.
• Automotive: Connecting wiring harnesses in automotive applications.

Features:

• Connector Type: Micro-Fit 3.0 Receptacle Housing.
• Number of Circuits: 12 circuits, allowing for multiple connections in a single housing.
• Pitch: 3.0 mm pitch, providing a compact and high-density connection.
• Material: Typically made from durable, high-temperature thermoplastic.
• Color: Usually black, but colors may vary depending on the specific application.
• Polarization: Features a polarization design to prevent mis mating.

Benefits:

• Compact Size: 3.0mm pitch enables high-density connections in space-constrained applications.
• Secure Connection: Provides a reliable and robust connection, ensuring signal integrity.
• Easy to Use: Designed for easy mating and unmating, simplifying assembly and maintenance.
• Polarization: Prevents incorrect connections, avoiding potential damage to the system.
• Versatile: Suitable for various wire-to-board and wire-to-wire applications.
• Durable: High-quality materials ensure long-term reliability.

Additional Details:

The 38723-6512 Micro-Fit 3.0 receptacle housing is designed to work with Micro-Fit 3.0 crimp terminals. It provides a secure and polarized connection, preventing accidental mis mating. The housing is typically made from a high-temperature thermoplastic material, which can withstand reflow soldering processes. The 3.0mm pitch allows for high-density connections, making it ideal for applications where space is limited. This connector is widely used in various industries due to its reliability and ease of use. It is important to use the correct crimp terminals and tooling to ensure a proper and reliable connection. The operating temperature range is typically -40°C to +105°C. Molex provides detailed specifications and application tooling information for this connector on their website.
