1201030001 Real Image
Same model may have multiple batches, images only for reference.

1201030001

Part No 1201030001
Manufacturer Molex, LLC
Catalog D - Sub Connectors
Description PROFIBUS Attachable D-Sub Connector with Diagnostics LEDs and Programming Port, 90° Angle
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Country of Origin PL
Current Rating 4 A
Depth 44 mm
ELV Compliant
Gender Female
Length 66 mm
Max Operating Temperature 80 °C
Min Operating Temperature -20 °C
Number of Contacts 9
Number of Positions 9
Number of Rows 2
Orientation Right Angle
Ratings IP67
RoHS Compliant
Termination IDC
Voltage Rating 30 V
Win Source Part Number 1167479-1201030001
Categories D - Sub Connectors
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 1201030001 CAD Model

Description

The Molex, LLC D-sub connector with Win Source Part Number 1167479-1201030001 is a female type. The supply and demand status is limited. This connector has nine positions and two rows with IDC termination. It has a voltage rating of 30V and a current rating of 4A. The Molex connector is suitable for use in various electronic circuits, including data communication and industrial control systems. It has a good quality and performance, making it a reliable choice for different applications.
