The RD100HHF1-101 is a 100W, 12.5V VHF power MOS FET manufactured by Mitsubishi Electric. It's designed for high-power amplification in VHF band applications, offering high gain and efficiency for reliable performance in demanding communication systems.

Applications

• VHF power amplifiers
• High-power mobile radio equipment
• Base station transmitters
• Industrial RF heating

Features

• High power gain: Typically 13 dB at 175 MHz
• High efficiency: Typically 60% at 175 MHz
• 100W output power
• MOS FET technology
• Hermetically sealed package
• Gold metallization

Benefits

• Enables high-power VHF power amplifiers
• Reduces power consumption and heat dissipation
• Provides robust and reliable operation
• Suitable for harsh environments
• Ensures long-term stability

Additional Details

The RD100HHF1-101 VHF power MOS FET is a robust device designed for high-power applications. Its high gain and efficiency contribute to reduced power consumption and improved system performance. The hermetically sealed package and gold metallization ensure reliable operation in harsh environments and long-term stability. This transistor is commonly used in high-power mobile radio equipment, base station transmitters, and industrial RF heating applications.

The RD100HHF1-101 is designed to withstand high voltage and current conditions, providing reliable performance in demanding applications. Its robust construction and stable characteristics make it a preferred choice for VHF power amplification. The device is carefully manufactured and tested to ensure consistent performance and long-term reliability.
