Products specifications Report Issue?

Category RF and Wireless - RF Amplifiers
Mfr Mini-Circuits
Package Tape & Reel
Product Status Active
Frequency 0Hz ~ 8GHz
P1dB 12dBm
Gain 8.2dB
Noise Figure 5.5dB
RF Type Cellular, CATV, DBS, PCS, WLAN
Voltage - Supply 3.2V ~ 3.6V
Current - Supply 40mA
Test Frequency 100MHz ~ 4GHz
Mounting Type Surface Mount
Package / Case 4-SMD, Gull Wing
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8542.33.0001
Win Source Part Number 123588-ERA-1SM+
Ultra Librarian 3D Model Ultra Librarian ERA-1SM+ CAD Model

Description

Product Overview

The ERA-1SM+ amplifier takes the performance of the original ERA-1SM to the next level, offering superior gain and noise reduction, ideal for high precision applications.

Applications

  • Precision Audio Systems
  • High-Fidelity Signal Processing
  • Advanced Electronic Testing
  • Professional Audio Equipment

Features and Benefits

  • Enhanced Gain Bandwidth: Provides excellent amplification for various signal types.
  • Superior Noise Handling: Reduces interference and boosts signal purity.
  • Durable and Efficient: Extends device longevity with minimal power consumption.
  • Sleek Design: Offers easy installation in compact designs.

The ERA-1SM+ is perfect for those needing cutting-edge performance in audio and signal amplification, ensuring ultimate clarity and fidelity.
