Microchip Technology USB2513B-AEZG USB 2.0 Hi-Speed Hub Controller

The USB2513B-AEZG is a versatile and high-performance USB 2.0 hub controller from the esteemed manufacturer, Microchip Technology. Designed to support the rapid data transfer rates of USB 2.0, this hub controller is an ideal solution for expanding the number of USB ports available on desktop and mobile systems, docking stations, monitors, and many other consumer electronics applications.

The device is fully compliant with the USB 2.0 Specification and supports high-speed (HS), full-speed (FS), and low-speed (LS) traffic, ensuring seamless operation with any USB-compliant data source. With its built-in transaction translator, the USB2513B-AEZG delivers high-bandwidth performance, allowing multiple FS and LS devices to operate at their respective speeds without compromising the data flow of HS devices.

Equipped with a MultiTRAK™ technology that provides multiple transaction translators, this hub controller ensures dedicated bandwidth to each downstream port, which is particularly beneficial when operating bandwidth-intensive USB devices simultaneously. The USB2513B-AEZG also features PortMap and PortSwap options, which provide a flexible way to configure port indicators and arrange the physical port layout to meet specific design requirements.

For enhanced power management, the USB2513B-AEZG includes advanced features like individual port power switching and over-current protection, which contribute to the safety and reliability of the connected devices. With its configurable non-removable device settings, the hub can emulate permanently attached devices, a feature that is particularly useful for embedded applications.

Integrating the USB2513B-AEZG into a design is made easier with its support for the SMBus interface, allowing for programmable vendor ID, product ID, device ID, and other manufacturer-specific information. This level of customization ensures that OEMs can tailor their products to meet specific market needs.

The USB2513B-AEZG is available in a compact 36-pin QFN package, making it suitable for space-constrained applications without compromising performance or functionality. Whether for expanding USB capabilities or for creating sophisticated consumer electronics, the USB2513B-AEZG from Microchip Technology stands as a robust and adaptable solution for USB connectivity.
