Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Driven Configuration Low-Side
Channel Type Single
Number of Drivers 1
Gate Type IGBT, N-Channel, P-Channel MOSFET
Supply Voltage - Operating 4.5 V to 18 V
Logic Voltage - VIL, VIH 0.8V, 2.4V
Current - Peak Output (Source, Sink) 13A, 13A
Input Type Non-Inverting
Rise and Fall Time 30ns, 32ns
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting Through Hole
Case / Package 8-PDIP
Win Source Part Number 1105980-TC4452VPA
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TC4452VPA CAD Model

Description

The TC4452VPA from Microchip Technology is a high-performance, robust motor driver designed for a wide range of applications. This device is capable of delivering a peak output current of up to 12A, making it suitable for driving larger motors in industrial, automotive, and consumer applications. With its high voltage operation of up to 18V, the TC4452VPA can easily handle the demands of complex systems.

One of the key features of the TC4452VPA is its integrated protection circuitry. This includes overcurrent protection, thermal shutdown, and undervoltage lockout, ensuring reliable operation and safeguarding the motor driver from potential damage caused by abnormal operating conditions. This makes the TC4452VPA an excellent choice for applications that require a high level of reliability and safety.

The TC4452VPA is also designed with ease of use in mind. It has a simple input logic interface that is compatible with standard CMOS or LSTTL outputs, allowing for straightforward integration into existing systems. Additionally, the motor driver's fast rise and fall times ensure efficient operation, minimizing power loss and heat generation during high-speed switching.

Microchip Technology's commitment to quality is evident in the TC4452VPA, with its robust design and long-lasting performance. The driver is housed in a power DIP-8 package, providing a compact footprint while still offering excellent thermal performance. This makes the TC4452VPA an ideal solution for space-constrained applications where maintaining a small form factor is essential.

Whether you're designing a new motor control system or upgrading an existing one, the TC4452VPA motor driver offers the power, protection, and performance needed to drive your project forward. With Microchip Technology's renowned support and resources, integrating the TC4452VPA into your design will be a seamless experience.
