Microchip Technology MCP6C02T-100H/Q8BVAO High-Side Current Sense Amplifier

The MCP6C02T-100H/Q8BVAO is a high-accuracy, high-side current sense amplifier designed by Microchip Technology, a leading manufacturer of microcontroller, mixed-signal, analog, and Flash-IP solutions. This device is specifically engineered to provide precise current measurement for a wide range of applications, including power management and monitoring systems.

Featuring a wide input common-mode voltage range from 3V to 65V, the MCP6C02T-100H/Q8BVAO is versatile enough to handle various operating conditions. This range allows the device to be used in both low and high-side sensing applications without the need for additional external components, simplifying the design and reducing the system cost.

The MCP6C02T-100H/Q8BVAO offers a fixed gain of 100 V/V, providing a high level of accuracy in current measurement. This gain allows for the detection of small voltage differences across a shunt resistor, translating them into a measurable output voltage proportional to the current flowing through the resistor. With its precision, this current sense amplifier is an excellent choice for applications requiring accurate power monitoring, such as battery chargers, power supplies, and motor control systems.

The device comes in a small, 6-pin, 2x2 DFN package, which makes it ideal for space-constrained applications. Its extended temperature range of -40°C to +125°C ensures reliable operation across various environmental conditions. Furthermore, the MCP6C02T-100H/Q8BVAO features a low quiescent current, contributing to the energy efficiency of the end application.

Key features of the MCP6C02T-100H/Q8BVAO include:

• High-side current sensing
• Wide input common-mode voltage range: 3V to 65V
• Fixed gain of 100 V/V for accurate measurements
• Extended temperature range: -40°C to +125°C
• Low quiescent current for power-sensitive applications
• Compact 6-pin, 2x2 DFN package

In summary, the Microchip Technology MCP6C02T-100H/Q8BVAO is a robust and reliable solution for designers looking to implement high-side current sensing in their applications. Its high accuracy, wide voltage range, and compact form factor make it an excellent choice for a variety of industrial, automotive, and consumer applications.
