Product Overview: MCP6004-E/SL

The MCP6004-E/SL is a quad operational amplifier (op-amp) designed and produced by Microchip Technology, a leading provider of microcontroller, mixed-signal, analog, and Flash-IP solutions. This product is tailored for low-power applications requiring multiple op-amps in a single package. It is an ideal choice for battery-powered devices and other applications where power efficiency is crucial.

Key Features

• Low Power Consumption: The MCP6004-E/SL is designed for low-power operation, consuming just 100 µA per amplifier. This characteristic makes it suitable for portable and battery-operated equipment where power conservation is vital.
• Rail-to-Rail Input/Output: With rail-to-rail input and output swing, the MCP6004-E/SL provides a wide dynamic range, making the most of the supply voltage range. This feature is particularly beneficial in single-supply operations and low-voltage applications.
• Wide Bandwidth: The device offers a gain bandwidth product of 1 MHz, which is optimal for a variety of applications including filters, amplifiers, and other analog functions.
• Extended Temperature Range: The MCP6004-E/SL can operate over an extended temperature range from -40°C to +125°C, ensuring reliable performance in a wide range of environmental conditions.
• Quad Configuration: This product features four op-amps in a single 14-pin SOIC package, saving space and reducing component count in complex circuits.
• Supply Voltage Range: It operates with a supply voltage range from 2.7V to 6.0V, accommodating various power supply options and system design flexibilities.

Applications

The MCP6004-E/SL is versatile and can be used in a broad spectrum of applications, including:

• Consumer Electronics
• Automotive Systems
• Medical Instruments
• Industrial Controls
• Analog Filters
• Sensor Interfaces
• Portable Devices

Microchip Technology's commitment to quality and performance is evident in the MCP6004-E/SL, making it a reliable choice for designers who require a high-performance quad operational amplifier with low power consumption.
