Microchip Technology MCP2562-E/SN CAN Transceiver

The MCP2562-E/SN is a high-performance CAN (Controller Area Network) transceiver manufactured by Microchip Technology. This device serves as an interface between a CAN protocol controller and the physical two-wire CAN bus. It is designed to provide differential transmit and receive capability for the CAN protocol controller, which is a standard communication bus for microcontroller-based applications in automotive and industrial environments.

With its robust design, the MCP2562-E/SN ensures reliable communication in harsh environments. It is compliant with the ISO 11898 standard, which specifies the high-speed physical media attachment for CAN communication up to 1 Mbps. Additionally, this transceiver features a wide operating voltage range from 4.5V to 5.5V, making it suitable for 5V systems and compatible with 3.3V devices when using a suitable level translator.

Key Features:

• Supports 1 Mbps operation, the maximum CAN specification rate.
• Operates from a single 5V supply (4.5V to 5.5V).
• Extended temperature range: -40°C to +125°C, suitable for automotive and industrial applications.
• Low quiescent current, making it ideal for battery-powered applications.
• Protection features include thermal shutdown, short-circuit protection, and an over-temperature shutdown.
• Available in an 8-pin SOIC package (SN suffix), which is widely used and easy to integrate into PCB designs.

The MCP2562-E/SN transceiver also includes a standby mode that allows the CAN controller to enter a low-power mode, with the CAN transceiver remaining receptive to CAN messages on the bus. This feature is particularly useful for energy-saving strategies in complex systems.

Microchip Technology's commitment to quality ensures that the MCP2562-E/SN transceiver is a reliable choice for designers looking to implement CAN in their automotive or industrial applications. The device's robustness, combined with its protection features and compatibility with various microcontroller logic levels, makes it a versatile and essential component in CAN-based communication networks.
