Products specifications

Categories Discrete Semiconductor Products
Features Diode Array 1 Pair Series Connection Standard 75 V 200mA Surface Mount 3-SMD, No Lead
Manufacturer Microchip Technology
Series Military, MIL-PRF-19500/116
Package Bulk
Speed Fast Recovery =< 500ns, > 200mA (Io)
Mounting Surface Mount
Package 3-SMD, No Lead
Case / Package UB
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0070
Other Part Number 1086-17578, 1086-17578-MIL
Quantity per package 1
Popularity High
Supply and Demand Status Balance
Win Source Part Number 922319-JANTX1N4148UBD
Ultra Librarian 3D Model Ultra Librarian JANTX1N4148UBD CAD Model

Description

Product Overview: JANTX1N4148UBD - Microchip Technology

The JANTX1N4148UBD is a high-reliability, small signal switching diode manufactured by Microchip Technology, a leader in microcontroller, mixed-signal, analog, and Flash-IP solutions. This diode is specifically designed to meet the stringent requirements of military applications and is compliant with the Joint Army/Navy (JAN) specifications, ensuring optimal performance under harsh conditions.

The JANTX1N4148UBD diode is characterized by its fast switching speed and low forward voltage drop, making it an ideal choice for high-speed switching applications in complex electronic systems. The device can handle a continuous reverse voltage of 100V, with a forward current of 200mA, which is sufficient for a wide range of signal processing and switching tasks.

This diode comes in a UB package, which is a surface-mount, hermetically sealed ceramic package that offers superior thermal performance and reliability. The UB package is designed to withstand mechanical stress and high-temperature environments, which is critical for military and aerospace applications where component durability is non-negotiable.

The JANTX1N4148UBD is also characterized by its low leakage current and high breakdown voltage, ensuring stable performance over its entire operating temperature range. This makes it suitable for use in environments with extreme temperature variations, which are common in aerospace and defense deployments.

Microchip Technology's commitment to quality is evident in the JANTX1N4148UBD, with rigorous testing protocols in place to guarantee that each diode meets the required specifications. The product is also supported by Microchip’s global customer service and technical support network, providing customers with the assistance they need throughout the product's lifecycle.

In summary, the JANTX1N4148UBD from Microchip Technology is a robust, high-performance switching diode that offers the reliability and durability needed for the most demanding military and aerospace applications, ensuring that critical systems function without fail in any scenario.
