Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tape and Reel
Type EL Lamp Driver
Frequency 40kHz ~ 200kHz
Supply Voltage (V) 2.5V ~ 4.5V
Supply Current 25mA
Dimming Yes
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 16-WFQFN Exposed Pad
Supplier Device Package 16-QFN (3x3)
Family Part Number HV861
Manufacturer Pack Quantity 3,300
MSL Level 1 (Unlimited)
Win Source Part Number 1182567-HV861K7-G
Manufacturer Homepage www.supertex.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian HV861K7-G CAD Model

Description

Microchip Technology HV861K7-G High Voltage Driver

The HV861K7-G is a sophisticated high voltage driver designed by Microchip Technology, a leader in microcontroller, mixed-signal, analog, and Flash-IP solutions. This component is tailored specifically for applications requiring precise control of high voltage signals, making it an ideal choice for a wide array of industrial, automotive, and consumer electronics.

Key Features

  • High Voltage Output: The HV861K7-G is capable of providing a high voltage output, which is essential for driving piezoelectric devices, LCD backlights, and other high impedance loads that demand higher voltages.
  • Low Power Consumption: Designed with energy efficiency in mind, this driver maintains low power consumption, thereby extending battery life in portable applications and reducing power costs in stationary installations.
  • Flexible Operating Voltage: The device operates over a wide range of supply voltages, offering versatility in various system designs and ensuring compatibility with different types of high voltage applications.
  • Robust Protection Features: The HV861K7-G comes with built-in protection features, such as over-temperature and over-current protection, enhancing the reliability and longevity of both the driver and the end application.
  • Compact Packaging: Available in a compact package, the HV861K7-G saves valuable board space, which is crucial for modern, space-constrained electronic designs.

Applications

The versatility of the HV861K7-G makes it suitable for a variety of applications, including:

  • Driving Piezoelectric Elements
  • Electrophoretic Displays (EPDs)
  • Portable Medical Devices
  • Industrial Automation Systems
  • Automotive Electronics

With its robust design and comprehensive feature set, the HV861K7-G from Microchip Technology stands out as a reliable and efficient solution for managing high voltage requirements in sophisticated electronic systems.
