The HV57908PG-G is a high-performance, serial to parallel converter with open-drain outputs from Microchip Technology. This advanced integrated circuit (IC) is designed to meet the demanding requirements of industrial, automotive, and consumer applications that require high-voltage drive capabilities. With its robust design and flexible features, the HV57908PG-G is an ideal solution for driving a wide range of high-voltage applications such as LED displays, dot matrix printers, and other types of visual indicators.

Key Features

• High-Voltage Output: The device can handle up to 80V on its output pins, enabling it to drive various high-voltage applications efficiently.
• Serial Interface: The IC supports a serial interface for input data, making it easy to connect with microcontrollers and other digital systems.
• Output Current Control: Each output channel can be programmed for constant current output, ensuring uniform illumination when driving LEDs.
• Thermal Shutdown Protection: Built-in thermal shutdown feature protects the IC from overheating, enhancing its reliability and lifespan.
• ESD Protection: The device includes electrostatic discharge protection, safeguarding it against unexpected voltage spikes.

Applications

• LED Display Panels
• Dot Matrix Printers
• General Purpose High-Voltage Indicators

The HV57908PG-G is supplied in a 44-pin PLCC (Plastic Leaded Chip Carrier) package, which is well-suited for surface mount technology (SMT) and ensures a compact footprint on the PCB. The package is also RoHS compliant, adhering to environmental standards and regulations.

With its combination of high-voltage capability, robust protection features, and ease of integration, the Microchip Technology HV57908PG-G is a versatile and reliable choice for designers looking to create sophisticated and durable high-voltage driving solutions.
