Category Crystals, Oscillators, Resonators - Pin Configurable/Selectable Oscillators
Mfr Microchip Technology
Series DSC60XX
Package Bag
Product Status Obsolete
Base Resonator MEMS
Type XO (Standard)
Frequency - Output 1 24MHz, 48MHz
Output CMOS
Voltage - Supply 1.71V ~ 3.63V
Frequency Stability ±25ppm
Temperature Range - Operating -40°C ~ 85°C
Current - Supply (Max) 1.3mA (Typ)
Size / Dimension 0.079" L x 0.063" W (2.00mm x 1.60mm)
Height 0.035" (0.89mm)
Package / Case 4-VFLGA
Standard Package 100
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1343266-DSC6023MI2A-00AC
Ultra Librarian 3D Model Ultra Librarian DSC6023MI2A-00AC CAD Model

Description

Product Overview: DSC6023MI2A-00AC by Microchip Technology

The DSC6023MI2A-00AC is a cutting-edge MEMS oscillator from Microchip Technology, renowned for its compact footprint and high reliability. This precision component is designed to meet the stringent requirements of modern electronic devices, offering a stable and accurate clock signal that is vital for system timing across a variety of applications.

Featuring a nominal frequency of 25.000 MHz, the DSC6023 series provides a stable timekeeping solution that is crucial for digital circuits to function correctly. Its low power consumption makes it an ideal choice for battery-operated devices, ensuring efficient power management without compromising performance.

The DSC6023MI2A-00AC is housed in a compact 2.5 x 2.0 mm package, which is well-suited for space-constrained applications. Its small size, however, does not detract from its performance or durability. The device is engineered to withstand harsh environmental conditions, maintaining its precision over a wide temperature range of -40°C to +85°C, making it suitable for both industrial and consumer applications.

This oscillator is characterized by its low jitter and high stability, which are critical for high-speed communication interfaces, microprocessors, and digital signal processing. Its fast start-up time is also a significant advantage, allowing systems to become operational without unnecessary delays.

Integration into existing designs is straightforward, thanks to its standard footprint and compatibility with other clock generation products. The DSC6023MI2A-00AC supports a supply voltage range of 1.71V to 3.63V, providing designers with flexibility in power supply design.

In summary, the Microchip Technology DSC6023MI2A-00AC MEMS oscillator is a high-performance, reliable, and energy-efficient solution that meets the needs of modern electronic systems. Its robust design, coupled with its ease of integration, makes it an excellent choice for designers looking to enhance the performance of their products.
