Products specifications

Category Crystals, Oscillators, Resonators - Pin Configurable/Selectable Oscillators
Mfr Microchip Technology
Series DSC60XX
Package Bag
Product Status Obsolete
Base Resonator MEMS
Type XO (Standard)
Frequency - Output 1 20MHz, 25MHz
Output CMOS
Voltage - Supply 1.71V ~ 3.63V
Frequency Stability ±25ppm
Temperature Range - Operating -40°C ~ 85°C
Current - Supply (Max) 1.3mA (Typ)
Size / Dimension 0.063" L x 0.047" W (1.60mm x 1.20mm)
Height 0.035" (0.89mm)
Package / Case 4-VFLGA
Standard Package 100
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1343205-DSC6023HI2A-00A4
Ultra Librarian 3D Model Ultra Librarian DSC6023HI2A-00A4 CAD Model

Description

Product Overview: DSC6023HI2A-00A4 by Microchip Technology

The DSC6023HI2A-00A4 is a cutting-edge MEMS oscillator designed and manufactured by Microchip Technology, a leader in the field of smart, connected, and secure embedded control solutions. This high-performance oscillator is part of Microchip's extensive range of frequency control products, offering a blend of low power consumption, high stability, and compact form factor.

Key Features

  • Frequency Range: The DSC6023 series is available in a wide frequency range, making it suitable for a variety of applications. This particular model operates at a fixed frequency of 00A4 MHz.
  • Stability: It provides excellent frequency stability, a critical feature for applications requiring precise timing.
  • Low Power Consumption: It is designed for energy-efficient operation, which is essential for battery-powered and portable devices.
  • Compact Package: The DSC6023HI2A-00A4 comes in a compact 2.5 x 2.0 mm package, making it ideal for space-constrained applications.
  • Temperature Range: This oscillator operates over an industrial temperature range, ensuring reliable performance under varying environmental conditions.
  • Supply Voltage: It is designed to work with a supply voltage that is typical for modern electronic circuits, ensuring compatibility with a wide range of products.

Applications

The DSC6023HI2A-00A4 is suitable for a diverse array of applications across different sectors. It is particularly well-suited for:

  • IoT devices
  • Wearable technology
  • Wireless communication systems
  • Portable electronics
  • Industrial controls and automation
  • Medical devices

Quality and Reliability

Microchip Technology is committed to delivering products that meet the highest standards of quality and reliability. The DSC6023HI2A-00A4 is no exception, with rigorous testing and quality control measures in place to ensure it performs to specifications under all specified conditions.

Support and Resources

Microchip Technology provides extensive technical support and resources for the DSC6023HI2A-00A4, including datasheets, application notes, and design guides. Customers can also access Microchip's customer support team for assistance with integration, programming, and other technical inquiries.

With its robust feature set and the backing of Microchip's renowned support, the DSC6023HI2A-00A4 is an excellent choice for designers looking to incorporate a reliable and efficient timing solution into their next project.
