The ATXMEGA128D4-CU is a cutting-edge 8/16-bit microcontroller from Microchip Technology, designed to offer a perfect blend of power efficiency and performance for a wide range of embedded applications. This MCU is part of the AVR® XMEGA® D4 family, which is renowned for its high-speed processing capabilities and low power consumption.
Key Features
- Advanced RISC Architecture: With 135 powerful instructions, most of which are executed in a single clock cycle, the ATXMEGA128D4-CU achieves throughputs approaching 1 MIPS per MHz, balancing power consumption and processing speed.
- Memory: It boasts 128KB of in-system self-programmable flash, 8KB boot code section, 8KB SRAM, and 2KB EEPROM for robust data storage and memory performance.
- High-precision Analog: The device includes a 12-bit analog-to-digital converter (ADC) and a 2-channel digital-to-analog converter (DAC) for precise analog signal management.
- Rich Peripherals: A variety of peripherals are integrated, including DMA (Direct Memory Access) controller, event system, and multiple serial communication modules.
- Power Efficiency: Multiple power-saving modes enable the conservation of energy for battery-powered applications without sacrificing performance.
- PicoPower Technology: Microchip's PicoPower technology allows for ultra-low power consumption, making it ideal for portable and power-sensitive devices.
Applications
The ATXMEGA128D4-CU is versatile and can be used in a multitude of applications such as industrial control systems, medical devices, utility metering, and home automation. Its robust feature set also makes it suitable for advanced motor control systems, real-time monitoring, and high-speed data processing tasks.
Package and Quality
This microcontroller comes in a 44-pin TQFP (Thin Quad Flat Pack) package, ensuring a compact footprint for space-constrained applications. Microchip Technology upholds high-quality standards, and the ATXMEGA128D4-CU is no exception, offering reliability and performance for professional-grade projects.
