SMCJ5.0A-TP Real Image SMCJ5.0A-TP Real Image
Same model may have multiple batches, images only for reference.
SMCJ5.0A-TP Real Image SMCJ5.0A-TP Real Image
SMCJ5.0A-TP Real Image SMCJ5.0A-TP Real Image
Same model may have multiple batches, images only for reference.

SMCJ5.0A-TP

Part No SMCJ5.0A-TP
Manufacturer Micro Commercial Co
Catalog TVS - Diodes
Description TVS DIODE 5V 9.2V DO214AB
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Micro Commercial Co
Packaging Reel
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 5V
Voltage - Breakdown (Min) 6.4V
Voltage - Clamping (Maximum) at Ipp 9.2V
Current - Peak Pulse (10/1000μs) 163A
Power - Peak Pulse 1500W (1.5kW)
Power Line Protection No
Applications Use For General
Temperature Range - Operating -55°C ~ 175°C
Mounting Style SMD
Manufacturer Package DO-214AB, SMC
Supplier Device Package DO-214AB (SMC)
Part Number Series SMCJ
Manufacturer Pack Quantity 3,000
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 809547-SMCJ5.0A-TP
Ultra Librarian 3D Model Ultra Librarian SMCJ5.0A-TP CAD Model

Description

Micro Commercial Co SMCJ5.0A-TP is a zener type electronic component.

  • Mounting Style: Surface Mount Device
  • Application: General Use
  • Channel: Unidirectional
  • Voltage Reverse Standoff: 5V
  • Voltage Breakdown: 6.4V
  • Current Peak Pulse: 163A
  • Power Peak Pulse: 1500W
  • Supplier Device Package: DO-214AB (SMC)
  • Temperature Range: -55°C to 175°C
  • Manufacturer Pack Quantity: 3,000
  • MSL Level: 1 (unlimited)
  • Voltage Clamping (Maximum) @ Ipp: 9.2V
  • Part Number Series: SMCJ
