Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr MDD
Series SMB
Package Tape & Reel
Product Status Active
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 60 V
Current - Average Rectified (Io) 2A
Voltage - Forward (Vf) (Max) @ If 700 mV @ 2 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 500 µA @ 60 V
Capacitance @ Vr, F 180pF @ 4V, 1MHz
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Supplier Device Package SMB
Operating Temperature - Junction -55°C ~ 125°C
Base Product Number SS26
Standard Package 6,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 676310-SS26B
Ultra Librarian 3D Model Ultra Librarian SS26B CAD Model

Description

The 676310-SS26B is a Schottky diode designed for use in rectifier applications.

  • Series: SMB
  • Package: Tape and reel
  • Voltage Rating: 60V
  • Average Rectified Current (Io): 2A
  • Forward Voltage Drop (Vf) @ 2A: 700mV
  • Reverse Leakage Current @ Maximum Reverse Voltage (Vr): 500µA
  • Capacitance @ 4V and 1MHz: 180pF
  • Mounting: Surface mountable
  • Operating Temperature Range: -55°C to 125°C
  • Product Status: Active
  • Standard Package: 6,000 pieces
  • Manufacturer: MDD
  • ECCN: EAR99
