KMB14F PACELEADER INDUSTRIAL
Same model may have multiple batches, images only for reference.

KMB14F

Part No KMB14F
Manufacturer MDD
Catalog Bridge Rectifiers
Description BRIDGE RECT 1PHASE 40V 1A KMB
Datasheet
KMB14F Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr MDD
Series MBF
Package Tape & Reel
Product Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 40 V
Current - Average Rectified (Io) 41 mA
Voltage - Forward (Vf) (Max) @ If 550 mV @ 1 A
Current - Reverse Leakage @ Vr 300 mA @ 40 V
Temperature Range - Operating -55°C ~ 1250°C (TJ)
Mounting Type Surface Mount
Package / Case 4-SMD, Flat Leads
Supplier Device Package MBF
Standard Package 10,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 610586-KMB14F
Ultra Librarian 3D Model Ultra Librarian KMB14F CAD Model

Description

The KMB14F is a bridge rectifier diode used in electronic circuits.

  • Series: MBF
  • Packaging: Tape and Reel
  • Standard Package: 10,000 Pieces
  • Rectification Type: Single-Phase
  • Average Rectified Current: 41 mA
  • Maximum Forward Voltage: 550 mV @ 1 A
  • Reverse Leakage Current: 300 mA @ 40 V
  • Mounting Type: Surface Mount
  • Package: 4-SMD, Flat Leads
  • Operating Temperature Range: -55°C to 1250°C
  • Status: Active
