RS2505M-C-LV
Same model may have multiple batches, images only for reference.

RS2505M-C-LV

Part No RS2505M-C-LV
Manufacturer Rectron USA
Catalog Bridge Rectifiers
Description BDGE RCT GLASS 600V LV 25A RS25M
Datasheet
RS2505M-C-LV Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr Rectron USA
Package Tube
Product Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 600 V
Current - Average Rectified (Io) 25 A
Voltage - Forward (Vf) (Max) @ If 920 mV @ 12.5 A
Current - Reverse Leakage @ Vr 5 µA @ 600 V
Temperature Range - Operating 150°C (TJ)
Mounting Type Through Hole
Package / Case 4-SIP, RS-25M
Supplier Device Package RS-25M
Standard Package 1,200 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 892371-RS2505M-C-LV
Ultra Librarian 3D Model Ultra Librarian RS2505M-C-LV CAD Model

Description

The 892371-RS2505M-C-LV is a single-phase bridge rectifier with an average rectified current of 25A.

  • Rectifier Type: Single-Phase Bridge
  • Average Rectified Current: 25A
  • Maximum Forward Voltage: 920mV @ 12.5A
  • Reverse Leakage Current: 5 µA @ 600V
  • Maximum Peak Reverse Voltage: 600V
  • Mounting Type: Through Hole
  • Package: 4-SIP
  • Operating Temperature: Up to 150°C
  • Manufacturer: Rectron USA
  • Standard Package: 1,200 pcs
