Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr MDD
Series KBP
Package Box
Product Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 600 V
Current - Average Rectified (Io) 125 mA
Voltage - Forward (Vf) (Max) @ If 1.1 V @ 3 A
Current - Reverse Leakage @ Vr 10 µA @ 600 V
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Package / Case 4-SIP, KBP
Supplier Device Package KBP
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 609988-KBP307
Ultra Librarian 3D Model Ultra Librarian KBP307 CAD Model

Description

The 609988-KBP307 is a single phase bridge rectifier.

  • Package: Box
  • Maximum Forward Voltage: 1.1V @ 3A
  • Reverse Leakage Current: 10µA @ 600V
  • Peak Reverse Voltage: 600V
  • Mounting: Through Hole
  • Operating Temperature Range: -55°C to 150°C
