The MAX825LEUK+T from Maxim Integrated is a highly efficient microprocessor (µP) supervisory circuit designed to monitor power supplies in µP and digital systems. It provides a significant level of system reliability and accuracy required in critical applications, ensuring that the system operates effectively under various conditions.

Key Features

• Precision Monitoring: This component offers precise monitoring of power supplies with a factory-set reset threshold voltage, ensuring that the system is protected from undervoltage conditions.
• Low Power Consumption: The MAX825LEUK+T is optimized for low power consumption, making it ideal for battery-operated and portable devices.
• Manual Reset Capability: It includes a manual reset input that allows the user to trigger a system reset as needed, providing additional control over system operation.
• Compact SOT-23 Packaging: The device comes in a small SOT-23 package, which saves space on the PCB and is suitable for compact electronic assemblies.
• High Accuracy: With its tight reset threshold accuracy and low supply current, this supervisory circuit is designed for high-accuracy applications.

Applications

The MAX825LEUK+T is versatile and can be used in a variety of applications, including:

• Computers and Servers
• Embedded Systems
• Battery-Powered Equipment
• Portable Consumer Electronics
• Industrial Controllers

Technical Specifications

• Package Type: SOT-23-5
• Operating Temperature Range: -40°C to +85°C
• Supply Voltage Range: 1.2V to 5.5V
• Reset Threshold Voltage: Factory set
• Reset Timeout: 140ms min

The MAX825LEUK+T is a testament to Maxim Integrated's commitment to providing innovative, high-quality products that enhance system reliability and performance. Whether you're designing a new system or upgrading an existing one, the MAX825LEUK+T is an excellent choice for your supervisory circuit needs.
