MAX4987AEETA+TG05 USB 2.0 High-Speed Analog Switch from Maxim Integrated

The MAX4987AEETA+TG05 is a superior USB 2.0 high-speed analog switch designed by Maxim Integrated, a leader in analog and mixed-signal engineering. This product offers an optimal solution for applications that require switching between USB sources or for multiplexing USB 2.0 signals. With its compact size and high performance, the MAX4987AEETA+TG05 is an ideal choice for portable electronics, docking stations, and other USB-enabled devices.

Key Features

• High-Speed USB 2.0 Interface: The device supports data rates up to 480Mbps, ensuring compatibility with high-speed USB 2.0 data transfers.
• Low On-Capacitance and On-Resistance: The switch features a low on-capacitance (C_ON) of 6pF (typical) and low on-resistance (R_ON) of 4.5Ω (typical), which minimizes signal distortion and ensures a high-quality signal path.
• Single-Supply Operation: Operating from a single 3.0V to 3.6V supply, it provides a convenient solution for battery-powered devices.
• ESD Protection: Integrated ESD protection circuitry guards the switch from electrostatic discharges, providing robustness and reliability with ±15kV Air Gap and ±8kV Contact discharge protection as per the IEC 61000-4-2 standard.
• Extended Temperature Range: Suitable for various environments, the switch operates over an extended temperature range from -40°C to +85°C.
• Space-Saving Package: Housed in a tiny 8-pin TDFN package (2mm x 2mm), the MAX4987AEETA+TG05 saves valuable board space in compact designs.

Applications

• Portable Consumer Electronics
• USB Peripheral Switching
• Desktop and Laptop Docking Stations
• USB Port Isolation

The MAX4987AEETA+TG05 analog switch from Maxim Integrated represents a blend of performance, efficiency, and size, making it a versatile component for designers who need reliable USB 2.0 signal switching capabilities. Its robust design and integrated features ensure a seamless and protected user experience across a wide array of USB-based applications.
