Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 50mV
Data Rate 2.5Mbps
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 021789-MAX485CSA+T
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name MAX485
Introduction Date February 01, 1996
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian MAX485CSA+T CAD Model

Description

The MAX485CSA+T from Maxim Integrated is a robust, low-power transceiver module designed for RS-485 and RS-422 communication protocols. This integrated circuit is engineered to provide reliable data transmission in multi-point networks and is particularly well-suited for long-distance and high-speed applications where power efficiency and minimal data line emissions are critical.

Key Features:

  • Low Quiescent Current: The device operates with a low supply current, typically 375µA, making it ideal for power-sensitive applications.
  • Slew-Rate Limitation: The MAX485CSA+T features a controlled slew rate, which reduces electromagnetic interference (EMI) and reflections caused by improperly terminated cables, allowing for error-free data transmission at rates up to 2.5Mbps.
  • Half-Duplex Communication: This transceiver is designed for half-duplex communication, enabling bidirectional communication over a single pair of wires, with the ability to connect up to 32 transceivers on the bus.
  • Extended Temperature Range: With an operating temperature range of -40°C to +85°C, it is suitable for industrial environments and outdoor applications.
  • Fail-Safe Receiver: The receiver input features a fail-safe design that ensures a logic-high receiver output when the input is open or shorted, or when no signals are present on the bus.
  • Industry-Standard 8-Pin SOIC Package: The device comes in a space-saving 8-pin SOIC package, making it easy to integrate into a variety of designs.
  • Lead-Free and RoHS Compliant: The MAX485CSA+T adheres to environmental regulations, being lead-free and compliant with the Restriction of Hazardous Substances (RoHS) directive.

Applications:

The transceiver's robust design and feature set make it an excellent choice for diverse applications, including industrial control systems, networked devices in building automation, and instrumentation networks. Its reliability and power efficiency are especially beneficial in remote sensors, security systems, and other devices that require long-term, maintenance-free operation.

With its combination of high-reliability, low-power consumption, and controlled data transmission characteristics, the MAX485CSA+T is a versatile component that enhances the performance and integrity of your RS-485/RS-422 communication systems.
