The MAX339ETE is a high-performance, low-voltage, quad analog switch from Maxim Integrated that offers superior switching characteristics for precision applications. This device is part of a family of CMOS analog ICs designed for routing analog and digital signals in a wide range of systems, including data acquisition, communication, and medical equipment.

Key Features

• Low Voltage Operation: The MAX339ETE operates from a single +1.8V to +5.5V supply, making it ideal for portable and battery-powered applications.
• Low On-Resistance: It features a low on-resistance (RON) of 100Ω max, which remains flat over the specified signal range, ensuring minimal signal distortion.
• High Off-Isolation: The device provides excellent off-isolation (-75dB at 1MHz), which minimizes crosstalk between switches.
• Low Crosstalk: At -83dB at 1MHz, the MAX339ETE ensures that the signal integrity is maintained across the channels.
• Single-Supply Operation: This simplifies the design by eliminating the need for dual supplies, thus reducing system complexity and power consumption.
• ESD Protection: The switch inputs and outputs are protected against electrostatic discharge (ESD) up to ±15kV Human Body Model (HBM), ensuring robustness and reliability in harsh environments.
• High-Speed Switching: The device offers fast switching times (turn-on time of 175ns and turn-off time of 145ns), suitable for high-speed signal routing.
• Extended Temperature Range: It operates over an extended temperature range of -40°C to +85°C, accommodating a wide range of industrial applications.

Applications

The MAX339ETE is versatile and can be used in various applications that require high-precision analog signal routing, such as:

• Sample and Hold Circuits
• Audio and Video Switching
• Data Acquisition Systems
• Communication Systems
• Medical Equipment
• Test Equipment

In summary, the MAX339ETE from Maxim Integrated is a reliable and efficient solution for designers looking to incorporate high-quality analog switching into their systems. Its low-voltage operation, high-speed switching, and robust ESD protection make it a preferred choice for a multitude of applications.
