Maxim Integrated MAX3311EEUB+T Product Overview

The MAX3311EEUB+T from Maxim Integrated is a high-performance, low-power, RS-232 transceiver with an integrated charge pump circuitry. This device is specifically designed to meet the stringent requirements of EIA/TIA-232-F and to provide electrical interface for communication between UART and serial-port connectors. The MAX3311EEUB+T is suitable for a wide range of applications, including portable or compact devices where space and power consumption are critical considerations.

Key Features

• Low Power Consumption: The MAX3311EEUB+T is designed for battery-powered applications, with a low supply current of 1µA (max) in shutdown mode, which helps to extend battery life.
• High Data Rate: Supports data rates up to 250kbps, making it ideal for high-speed serial communication.
• Single Supply Operation: Operates from a single +3.0V to +5.5V power supply, which simplifies power supply design.
• Integrated Charge Pump: The onboard charge pump circuit generates the necessary RS-232 voltage levels (+/-10V) from a single power supply, eliminating the need for a dual power supply.
• ESD Protection: Features ±15kV electrostatic discharge (ESD) protection on transmitter outputs and receiver inputs to prevent damage from static electricity.
• Small Package Size: Available in a space-saving 10-pin µMAX package, perfect for applications where board space is at a premium.

Applications

• Portable Instruments
• Notebook, Subnotebook, and Palmtop Computers
• Battery-Powered Equipment
• Handheld Equipment
• Peripherals

The MAX3311EEUB+T transceiver provides reliable, high-speed data transmission and reception for a variety of digital communication systems. Its robust feature set and compact form factor make it an excellent choice for designers looking to enhance the connectivity of their products while maintaining efficiency and space economy.

With Maxim Integrated's reputation for quality and reliability, the MAX3311EEUB+T is a smart choice for your next design project that requires RS-232 communication capabilities.
