Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Maxim Integrated
Packaging Tube
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 3/5
Duplex Full
Receiver Hysteresis 500mV
Data Rate 1Mbps
Operating Supply Voltage 3 V ~ 5.5 V
Operating Temperature Range 0°C ~ 70°C
Mounting SMD
Package 28-SSOP (0.209", 5.30mm Width)
Manufacturer Package 28-SSOP
Win Source Part Number 785916-MAX3245ECAI+
Popularity Medium
Supply and Demand Status Limited
Family Name MAX3245E
Introduction Date January 01, 1998
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian MAX3245ECAI+ CAD Model

Description

Maxim Integrated's MAX3245ECAI+: High-Speed RS-232 Transceiver

The MAX3245ECAI+ is an advanced high-speed RS-232 transceiver from Maxim Integrated, designed to meet the demanding requirements of modern communication systems. This transceiver is capable of data rates up to 1Mbps, making it an ideal choice for applications that require fast and reliable data transfer over RS-232 interfaces.

Encased in a 28-pin SSOP package, the MAX3245ECAI+ offers a convenient and space-saving solution for designers. It operates from a single +3.0V to +5.5V supply, which allows for flexible integration into a variety of systems without the need for additional power supplies. This feature is particularly beneficial for portable and battery-operated devices where power efficiency is critical.

One of the standout features of the MAX3245ECAI+ is its integrated electrostatic discharge (ESD) protection. With ±15kV ESD protection on transmitter outputs and receiver inputs (per the Human Body Model), this transceiver provides robust protection against the damaging effects of static electricity, enhancing the reliability and longevity of your product.

The MAX3245ECAI+ supports the full-duplex communication necessary for complex tasks. It includes three drivers and five receivers, which means it can handle multiple data streams simultaneously. Additionally, the device incorporates a proprietary low-dropout transmitter output stage, delivering true RS-232 performance from a 3.0V to 5.5V supply with a dual charge pump. This feature ensures that the transceiver maintains RS-232 output levels even during low-power supply conditions.

For energy-conscious applications, the MAX3245ECAI+ offers a shutdown mode that reduces the supply current to 1µA, further extending battery life. Moreover, the device is fully compliant with the TIA/EIA-232-F standards and ensures reliable communication even in harsh industrial environments.

In summary, the MAX3245ECAI+ from Maxim Integrated is a versatile, high-speed RS-232 transceiver that offers excellent ESD protection, low-power operation, and true RS-232 performance. It is an excellent choice for engineers looking to implement reliable data communication in their designs with minimal power consumption and maximum protection against electrical disturbances.
