Products specifications

Manufacturer Maxim Integrated
Packaging Tray
Type Transceiver
Protocol T1/E1/J1
Number of Drivers/Receivers 8/8
Duplex Full
Supply Voltage (V) 3.135V ~ 3.465V
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 256-BGA, CSBGA
Supplier Device Package 256-CSBGA (17x17)
Part Number Series DS26518
Manufacturer Pack Quantity 90
MSL Level 1 (Unlimited)
Popularity Low
Supply and Demand Status Limited
Win Source Part Number 812696-DS26518GN
Ultra Librarian 3D Model Ultra Librarian DS26518GN CAD Model

Description

The Maxim Integrated DS26518GN is a versatile and high-performance multi-protocol transceiver designed to handle a wide range of communication protocols. This device is a crucial component for applications requiring reliable data transmission and reception across different interface standards.

Key Features

  • Multi-Protocol Support: The DS26518GN supports various protocols including T1, E1, J1, and more, making it suitable for telecommunications, networking, and data acquisition systems.
  • Integrated Line Interface Units: It contains complete line interface units (LIUs) for each protocol, providing a seamless and efficient connection to physical media.
  • Flexible Configuration: The device can be configured for different modes of operation, enabling its use in a broad range of applications and systems.
  • High Integration: The device integrates several functions into a single chip, reducing the need for external components and simplifying design.
  • Low Power Consumption: Designed with power efficiency in mind, the DS26518GN is ideal for power-sensitive applications.

Applications

The DS26518GN is well-suited for a variety of applications, including but not limited to:

  • Telecommunications equipment
  • Wireless base station interconnect
  • Network routers and switches
  • PBX and IP-PBX systems
  • Test equipment for communication systems

Technical Specifications

Parameter Value Supply Voltage 3.3V Operating Temperature -40°C to +85°C Package Type 68-Pin LQFP Data Rate Up to 2.048 Mbps

The DS26518GN from Maxim Integrated offers a reliable solution for multi-protocol data communication with its robust feature set and flexible design. Its high integration and low power consumption make it a smart choice for modern communication systems.
