The DS1775R/TR from Maxim Integrated is a compact, high-precision digital thermometer and thermostat that provides temperature readings with a resolution of 9 to 12 bits (configurable). This versatile device is designed to be used in a wide range of applications, including environmental control, system thermal management, and industrial process monitoring.

Key Features

• High Accuracy: The DS1775R/TR offers excellent temperature accuracy and resolution, ensuring precise temperature monitoring and control.
• Programmable Resolution: Users can select the resolution from 9 to 12 bits, allowing them to balance the need for precision with the desire for faster temperature conversion times.
• Simple Interface: The device communicates over a 2-wire, I²C-compatible serial interface, which is widely used and simplifies integration into existing systems.
• Low Power Consumption: Designed for energy efficiency, the DS1775R/TR is suitable for battery-powered applications, as it helps to extend the life of the power source.
• Wide Operating Range: The device operates over a -55°C to +125°C temperature range, making it robust enough for challenging environmental conditions.
• Compact Package: It is available in a small SOT-23 package, which is ideal for space-constrained applications.

Applications

The DS1775R/TR is a versatile component that can be used in various applications such as:

• Office electronics
• Cellular phones
• Notebook computers
• Environmental monitoring
• Industrial control systems
• Portable medical devices

Ordering Information

The DS1775R/TR is available in tape and reel format, denoted by the suffix "/TR", which facilitates automated assembly processes, making it a convenient choice for high-volume production. For detailed ordering and product information, please refer to the Maxim Integrated official website or contact their sales and support team.
