The TLPGE1005B is a green LED manufactured by Marktech Optoelectronics. It is designed for a variety of indication and illumination applications. This LED utilizes advanced AlInGaP (Aluminum Indium Gallium Phosphide) material technology to achieve high luminous efficiency and reliable performance.

Applications:

• Status indicators on electronic devices
• Backlighting for LCD displays and keypads
• Panel indicators in industrial equipment
• Automotive lighting applications (e.g., dashboard indicators)
• General illumination purposes

Features:

• High luminous intensity: Provides a bright and easily visible light output.
• Green color: Offers a vibrant green light emission.
• Compact size: The small package size allows for easy integration into various designs.
• AlInGaP material: Ensures high efficiency and reliability.
• Long lifespan: Designed for extended operation.
• Low forward voltage: Reduces power consumption.

Benefits:

• Enhanced visibility: The high luminous intensity ensures clear indication in different lighting conditions.
• Energy efficiency: Low forward voltage contributes to reduced power consumption and lower operating costs.
• Space-saving design: The compact size allows for integration into space-constrained applications.
• Reliable performance: The AlInGaP material ensures consistent and dependable operation.
• Long-term cost savings: The long lifespan reduces the need for frequent replacements.

Additional Details:

The TLPGE1005B features a typical forward voltage of around 2.1V and a forward current of approximately 20mA. The viewing angle is generally around 140 degrees, providing a wide dispersion of light. It is typically packaged in a surface mount (SMT) configuration, making it suitable for automated assembly processes. This LED is RoHS compliant, meaning it is free from hazardous substances.

It is important to consult the manufacturer's datasheet for precise electrical and optical characteristics, as these parameters may vary slightly between production lots. The datasheet also provides essential information on handling, storage, and soldering recommendations to ensure optimal performance and longevity of the LED.
