MX29LV040CQI-55Q Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Memory - Memory
Mfr Macronix
Series MX29LV
Package Tray
Product Status Not For New Designs
Programmable Not Verified
Memory Type Non-Volatile
Memory Format FLASH
Technology FLASH - NOR
Memory Size 4Mbit
Memory Organization 512K x 8
Memory Interface Parallel
Write Cycle Time - Word, Page 55ns
Access Time 55 ns
Voltage - Supply 2.7V ~ 3.6V
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case 32-LCC (J-Lead)
Supplier Device Package 32-PLCC (11.43x14.05)
Base Product Number MX29LV040
Standard Package 128 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.32.0071
Win Source Part Number 646207-MX29LV040CQI-55Q
Ultra Librarian 3D Model Ultra Librarian MX29LV040CQI-55Q CAD Model

Description

The MX29LV040CQI-55Q is a 4Mbit FLASH - NOR memory integrated circuit from the MX29LV series by Macronix.

  • Application: Non-volatile memory
  • Supply Voltage: 2.7V to 3.6V
  • Access Time: 55ns
  • Write Cycle Time: 55ns
  • Mounting: Surface Mountable
  • Package: 32-LCC
  • Memory Interface: Parallel
  • Memory Organization: 512K x 8
  • Recommendation: Not recommended for new designs
