Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Macronix
Packaging Tray
Status Active
Memory Format FLASH
Technology FLASH - NOR
Memory Size 256Mb (32M x 8)
Access Time 90ns
Supply Voltage - Operating 2.7 V to 3.6 V
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 56-TSOP
Win Source Part Number 041823-MX29GL256FLT2I-90Q
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MX29GL256F
Introduction Date December 10, 2009
ECCN 3A991.b.1.a
Country of Origin Taiwan
Estimated EOL Date 2023
Quantity per package 96
Ultra Librarian 3D Model Ultra Librarian MX29GL256FLT2I-90Q CAD Model

Description

The Macronix MX29GL256F is a high-performance 256Mb (32M x 8) FLASH-NOR memory chip. It has an access time of 90ns and operates @ a temperature range of -40°C to 85°C (TA).

  • Applications: integrated circuits
  • Package: 56-TSOP package
  • Operating Voltage: 2.7V to 3.6V
  • Popularity: High
  • Supply and Demand Status: Balance
  • EOL Date: 2023
