MASWSS0151TR-3000 M/A-Com Technology Solutions MASWSS0151TR-3000 Real Image MASWSS0151TR-3000 real image 2 MASWSS0151TR-3000 real image 3 MASWSS0151TR-3000 real image 4 MASWSS0151TR-3000 label picture MASWSS0151TR-3000 label picture 2 MASWSS0151TR-3000 label picture 3 MASWSS0151TR-3000 label picture 4 MASWSS0151TR-3000 label picture 5 MASWSS0151TR-3000 label picture 6
Same model may have multiple batches, images only for reference.
MASWSS0151TR-3000 M/A-Com Technology Solutions MASWSS0151TR-3000 Real Image MASWSS0151TR-3000 real image 2 MASWSS0151TR-3000 real image 3 MASWSS0151TR-3000 real image 4 MASWSS0151TR-3000 label picture MASWSS0151TR-3000 label picture 2 MASWSS0151TR-3000 label picture 3 MASWSS0151TR-3000 label picture 4 MASWSS0151TR-3000 label picture 5 MASWSS0151TR-3000 label picture 6
MASWSS0151TR-3000 M/A-Com Technology Solutions MASWSS0151TR-3000 Real Image MASWSS0151TR-3000 real image 2 MASWSS0151TR-3000 real image 3 MASWSS0151TR-3000 real image 4 MASWSS0151TR-3000 label picture MASWSS0151TR-3000 label picture 2 MASWSS0151TR-3000 label picture 3 MASWSS0151TR-3000 label picture 4 MASWSS0151TR-3000 label picture 5 MASWSS0151TR-3000 label picture 6
Same model may have multiple batches, images only for reference.

MASWSS0151TR-3000

Part No MASWSS0151TR-3000
Manufacturer M/A-Com Technology Solutions
Catalog RF Switches
Description SWITCH SPDT SC70-6LD
Datasheet
MASWSS0151TR-3000 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer M/A-Com Technology Solutions
Packaging Reel
Part Status Active
Frequency - Lower DC
Frequency - Upper 3GHz
Isolation @ Frequency 21dB @ 3GHz (typ)
Insertion Loss @ Frequency 0.65dB @ 3GHz
Topology Reflective
Circuit SPDT
P1dB 31dBm
Impedance 50 Ohm
Temperature Range - Operating -40°C ~ 85°C
RF Type Bluetooth, WLAN
Case 6-TSSOP, SC-88, SOT-363
Supplier Device Package SC-70-6 (SOT-363)
Win Source Part Number MASWSS0151TR-3000-207805
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name MASWSS0151
Introduction Date May 20, 2009
Country of Origin Malaysia, Taiwan
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian MASWSS0151TR-3000 CAD Model

Description

The MASWSS0151TR-3000-207805 from M/A-Com Technology Solutions is a reflective SPDT switch circuit with an impedance of 50 Ohm and a frequency range of DC to 3GHz. It features an isolation of 21dB @ 3GHz (typ) and an insertion loss of 0.65dB @ 3GHz. The RF type of this switch circuit is Bluetooth and WLAN. This product is supplied in SC-70-6 (SOT-363) package and has an operating temperature range of -40°C to 85°C. The MASWSS0151TR-3000-207805 is a common-used part with high popularity and sufficient supply and demand status. The estimated EOL date for this product is 2024.
