LXML-PL01-0040

Part No LXML-PL01-0040
Manufacturer Lumileds
Catalog LED Lighting - Color
Description LUXEON Rebel and LUXEON Rebel ES Color Portfolio | LED LUXEON REBEL AMBER SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Optoelectronics
Manufacturer Lumileds
Packaging Tape and Reel
Color Amber
Wavelength 590nm
Current - Test 350mA
Voltage - Forward (Vf) 2.1V
Lumens/Watt at Current - Test 60 lm/W
Current - Max 700mA
Flux at Current/Temperature - Test 44lm (40lm ~ 48lm)
Test Temperature Condition 25°C
Viewing Angle 125°
Mounting Style SMD
Manufacturer Package 1812 (4532 Metric)
Supplier Device Package SMD
Parts Dimension 0.177" L x 0.120" W (4.49mm x 3.05mm)
Height - Seated (Maximum) 0.083" (2.10mm)
Thermal Resistance of Package 12°C/W
Manufacturer Pack Quantity 1,000
MSL Level 1 (Unlimited)
Win Source Part Number 1209786-LXML-PL01-0040
Manufacturer Homepage www.luxeon.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LXML-PL01-0040 CAD Model

Description

The Lumileds LXML-PL01-0040 is an amber surface-mount LED emitter designed for use in optoelectronic applications.

  • GPTDescription: The device has a maximum current of 700mA and a viewing angle of 125 degrees.
  • GPTDescription: The thermal resistance of the package is 12 degrees Celsius per watt.
  • GPTDescription: The SMD package has a height of 0.083 inches and a dimension of 0.177 inches in length and 0.120 inches in width.
  • GPTDescription: The device has a voltage-forward of 2.1V and a lumens/watt of 60 lm/W @ current-test of 350mA.
  • GPTDescription: The flux @ current/temperature-test is 44lm @ 25 degrees Celsius.
  • GPTDescription: The device is supplied in a tape and reel package with a manufacturer pack quantity of 1,000.
