LXML-PD01-0050 Lumileds
Same model may have multiple batches, images only for reference.

LXML-PD01-0050

Part No LXML-PD01-0050
Manufacturer Lumileds
Catalog LED Lighting - Color
Description RED
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Optoelectronics - Color LED Lighting
Mfr Lumileds
Series LUXEON Rebel Color Line
Package Tape & Reel
Product Status Active
Color Red
Wavelength 633nm
Current - Test 350mA
Voltage - Forward (Vf) (Typ) 2.9V
Lumens/Watt @ Current - Test 51 lm/W
Current - Max 700mA
Luminous Flux @ Current/Temperature 52lm (Typ)
Temperature - Test 25°C
Viewing Angle 125°
Mounting Type Surface Mount
Package / Case 1812 (4532 Metric)
Supplier Device Package 1812
Size / Dimension 0.177" L x 0.120" W (4.49mm x 3.05mm)
Height - Seated (Max) 0.083" (2.10mm)
Base Product Number LXML
Standard Package 1,000 pcs
REACH Status REACH Unaffected
Win Source Part Number 627095-LXML-PD01-0050
Ultra Librarian 3D Model Ultra Librarian LXML-PD01-0050 CAD Model

Description

The LXML-PD01-0050 is a red color LED lighting component that belongs to the Optoelectronics - Color LED Lighting category. It is part of the LUXEON Rebel Color Line series. The LXML-PD01-0050 has a size of 0.177" L x 0.120" W and a height of 0.083". It is designed for applications that require colored lighting. The maximum current it can handle is 700mA, and it has a viewing angle of 125°. The forward voltage is 2.9V, and the wavelength is 633nm. The LXML-PD01-0050 has a luminous flux of 52lm @ a current of 350mA and a temperature of 25°C. It is surface mount mounted and comes in a 1812 package. The LXML-PD01-0050 is an active product manufactured by Lumileds.
