The SML-LXL1206QC-TR is a surface mount LED manufactured by Lumex Opto/Components Inc. It's a compact, high-efficiency LED designed for a variety of indicator and backlighting applications. The '1206' in the part number indicates the package size (1.2mm x 0.6mm).

Applications

• Status indicators on consumer electronics (e.g., smartphones, laptops, gaming consoles)
• Backlighting for LCDs, keypads, and switches
• Indicator lights in industrial control panels
• Medical equipment indicators
• Automotive dashboard indicators

Features

• Ultra-compact 1206 package size
• High luminous intensity for bright visibility
• Wide viewing angle for easy observation
• Surface mount technology (SMT) for automated assembly
• RoHS compliant, lead-free construction

Benefits

• Space-saving design allows for high-density PCB layouts
• Enhanced visibility due to high brightness and wide viewing angle
• Easy integration into automated manufacturing processes
• Environmentally friendly due to RoHS compliance
• Long lifespan for reliable performance

Additional Details

The SML-LXL1206QC-TR is typically made using AlInGaP or InGaN material, depending on the color emitted. The forward voltage is typically around 2.0-3.5V, and the forward current is typically 20mA. This LED is designed for reflow soldering processes. The 'QC' in the part number may denote a specific color or intensity binning. The 'TR' suffix indicates that it's supplied on tape and reel for automated pick-and-place assembly. Consult the Lumex datasheet for detailed electrical and optical specifications, including wavelength, luminous intensity, and viewing angle.
