SP3012-04HTG Real Image SP3012-04HTG Real Image
Same model may have multiple batches, images only for reference.
SP3012-04HTG Real Image SP3012-04HTG Real Image
SP3012-04HTG Real Image SP3012-04HTG Real Image
Same model may have multiple batches, images only for reference.

SP3012-04HTG

Part No SP3012-04HTG
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 5VWM 7VC SOT23-6
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Littelfuse Inc.
Series SP3012, SPA®
Package Tape & Reel
Product Status Obsolete
Type Steering (Rail to Rail)
Unidirectional Channels 4
Voltage - Reverse Standoff (Typ) 5V (Max)
Voltage - Clamping (Max) @ Ipp 7V (Typ)
Current - Peak Pulse (10/1000µs) 4A (8/20µs)
Power Line Protection Yes
Applications General Purpose
Capacitance @ Frequency 0.5pF @ 1MHz
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case SOT-23-6
Supplier Device Package SOT-23-6
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0080
California Prop 65 Warning Information
Win Source Part Number 845794-SP3012-04HTG
Ultra Librarian 3D Model Ultra Librarian SP3012-04HTG CAD Model

Description

The SP3012-04HTG is a TVS diode designed for transient voltage suppression in electronic circuits.

  • Type: TVS Diode (Steering Diode)
  • Series: SP3012, SPA®
  • Package: Tape & reel
  • Quantity per Package: 3,000 pieces
  • Channels: 4 Unidirectional
  • Reverse Standoff Voltage: 5V
  • Clamping Voltage: 7V (typical) @ 4A (8/20μs)
  • Mounting Type: Surface Mount
  • Package/Case: SOT-23-6
  • Application: General Purpose
  • Product Status: Obsolete
  • Manufacturer: Littelfuse Inc.
  • Warning: Contains materials that may require a warning under California Prop 65
