SP3002-04JTG Real Image SP3002-04JTG real image6363
Same model may have multiple batches, images only for reference.
SP3002-04JTG Real Image SP3002-04JTG real image6363
SP3002-04JTG Real Image SP3002-04JTG real image6363
Same model may have multiple batches, images only for reference.

SP3002-04JTG

Part No SP3002-04JTG
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 6VWM 13VC SC70-6
Datasheet
SP3002-04JTG Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Packaging Reel - TR
Status Active
Type Steering (Rail to Rail)
Unidirectional Channels 4
STAND-OFF Voltage (Vwm) 6V (Max)
Max Clamping Voltage 13V
Peak Pulse Current(Ippm) 4.5A (8/20μs)
Power Line Protection Yes
Applications General Purpose
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package SC-70-6
Win Source Part Number 120479-SP3002-04JTG
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SP3002-04JTG CAD Model

Description

The Littelfuse Inc. 120479-SP3002-04JTG is a steering (rail to rail) type circuit protection component that is designed for general purpose applications.

  • Stand-off Voltage (Vwm): 6V (max)
  • Channels: 4 unidirectional
  • Peak Pulse Current (Ippm): 4.5A (8/20μs)
  • Max Clamping Voltage: 13V
  • Mounting: SMD (SMT)
  • Case/Package: SC-70-6
  • Supply and Demand Status: balanced
