Same model may have multiple batches, images only for reference.
SMD2920P185TF Real Image
Same model may have multiple batches, images only for reference.

SMD2920P185TF

Part No SMD2920P185TF
Manufacturer Littelfuse Inc.
Catalog PTC Resettable Fuses
Description FUSE RESET 1.85A 33V 2920 SMD
Datasheet
SMD2920P185TF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Packaging Reel - TR
Status Obsolete(EOL)
Type Polymeric
Voltage - Max 33V
Current - Max 40A
Current - Hold (Ih) (Max) 1.85A
Current - Trip (It) 3.7A
Time to Trip 2.5s
Resistance - Initial (Ri) (Min) 65 mOhm
Resistance - Post Trip (R1) (Max) 150 mOhm
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Dimension 0.290" L x 0.202" W (7.36mm x 5.12mm)
Thickness (Max) 0.039" (1.00mm)
Approvals cURus, TUV
Win Source Part Number 211833-SMD2920P185TF
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SMD2920P185TF CAD Model

Description

The SMD2920P185TF series is a type of Polymeric circuit protection device manufactured by Littelfuse Inc.

  • Mounting: Surface mount device (SMD)
  • Package: Reel - TR
  • Voltage Max: 33V
  • Current Max: 40A
  • Current Hold: 1.85A (maximum)
  • Current Trip: 3.7A
  • Time to Trip: 2.5s
  • Resistance Initial: 65 mOhm (minimum)
  • Resistance Post-Trip: 150 mOhm (maximum)
  • Temperature Range: -40°C to 85°C
