Same model may have multiple batches, images only for reference.

SMAJ188A

Name: SMAJ188A
Brand: Littelfuse Inc.
SKU: 668573
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SMAJ188A
Manufacturer	Littelfuse Inc.
Catalog	TVS - Diodes
Description	TVS DIODE SMA SMT
Datasheet	SMAJ188A Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr	Littelfuse Inc.
Series	SMAJ
Package	Tape & Reel
Product Status	Active
Type	Zener
Unidirectional Channels	1
Voltage - Reverse Standoff (Typ)	188V
Voltage - Breakdown (Min)	209V
Voltage - Clamping (Max) @ Ipp	304V
Current - Peak Pulse (10/1000µs)	1.4A
Power - Peak Pulse	400W
Power Line Protection	No
Applications	Telecom
Temperature Range - Operating	-65°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	DO-214AC, SMA
Supplier Device Package	DO-214AC (SMA)
Standard Package	5,000 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.10.0080
California Prop 65	Warning Information
Win Source Part Number	668573-SMAJ188A
Ultra Librarian 3D Model	Ultra Librarian SMAJ188A CAD Model

Alternative Products

Description

The 668573-SMAJ188A is a unidirectional TVS diode from the SMAJ series by Littelfuse Inc.

Series: SMAJ
Manufacturer: Littelfuse Inc.
Design: Designed for circuit protection in telecom applications.
Function: Provides reliable protection against transient voltage spikes.
Reverse Standoff Voltage: 188V
Breakdown Voltage: 209V
Clamping Voltage @ Peak Pulse Current: 304V
Power Rating: 400W
Peak Pulse Current: 1.4A
Mounting Type: Surface mount
Case: DO-214AC, SMA
Status: Active product
