Same model may have multiple batches, images only for reference.

SM24CANA-02HTG

Name: SM24CANA-02HTG
Brand: Littelfuse Inc.
SKU: 326506
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SM24CANA-02HTG
Manufacturer	Littelfuse Inc.
Catalog	TVS - Diodes
Description	ESD Suppressor Diode TVS Bi-Dir 24V Automotive 3-Pin SOT-23 T/R / TVS DIODE 24VWM 50VC SOT23
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Circuit Protection
Manufacturer	Littelfuse Inc.
Packaging	Reel - TR
Status	Active
Type	Zener
Bidirectional Channels	2
STAND-OFF Voltage (Vwm)	24V (Max)
Minimum Breakdown Voltage	26.7V
Max Clamping Voltage	50V
Peak Pulse Current(Ippm)	3A (8/20μs)
Power Dissipation - Pd	200W
Applications	Automotive, CAN
Capacitance @ Frequency	11pF @ 1MHz
Temperature Range - Operating	-40°C to 125°C (TJ)
Mounting	SMD (SMT)
Case / Package	SOT-23-3
Win Source Part Number	102122-SM24CANA-02HTG
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	SM24CANA-02
Introduction Date	May 22, 2014
ECCN	EAR99
Country of Origin	Thailand
Halogen Free	Compliant
Estimated EOL Date	2022
Ultra Librarian 3D Model	Ultra Librarian SM24CANA-02HTG CAD Model

Alternative Products

Description

The Littelfuse Inc. SM24CANA-02HTG is a bidirectional Zener diode with two channels.

Capacitance: 11pF @ 1MHz
Stand-Off Voltage: 24V (max)
Minimum Breakdown Voltage: 26.7V
Max Clamping Voltage: 50V
Peak Pulse Current: 3A (8/20μs)
Power Dissipation: 200W
Applications: Automotive and CAN
Temperature Range: -40°C to 125°C
Mounting Technology: SMD (SMT)
Packaging: SOT-23-3
Supply and Demand Status: Limited
