5.0SMDJ58A Real Image 5.0SMDJ58A Real Image
Same model may have multiple batches, images only for reference.
5.0SMDJ58A Real Image 5.0SMDJ58A Real Image
5.0SMDJ58A Real Image 5.0SMDJ58A Real Image
Same model may have multiple batches, images only for reference.

5.0SMDJ58A

Part No 5.0SMDJ58A
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 58VWM 93.6VC SMD
Datasheet
5.0SMDJ58A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 58V
Minimum Breakdown Voltage 64.4V
Max Clamping Voltage 93.6V
Peak Pulse Current(Ippm) 53.5A
Power Dissipation - Pd 5000W (5kW)
Applications General Purpose
Temperature Range - Operating -65°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package DO-214AB (SMCJ)
Win Source Part Number 1005855-5.0SMDJ58A
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 5.0SMDJ58A CAD Model

Description

The Littelfuse Inc. 1005855-5.0SMDJ58A zener is a high-quality electronic component that features a stand-off voltage (Vwm) of 58V.

  • Mounting: SMD (SMT)
  • Type: Zener
  • Category: Circuit Protection
  • Status: Active
  • Temperature Range: -65°C to 150°C (TJ)
  • Case/Package: DO-214AB (SMCJ)
  • Peak Pulse Current(Ippm): 53.5A
  • Power Dissipation - Pd: 5000W (5kW)
  • Supply and Demand Status: Balanced
